Vacuum Pumps

These pumps achieve vacuum upto 737 mm (29.0' Hg) for single stage and upto 754.4 mm (29.7" Hg) for two stage configuration, at sea level.

Category:

Maxwell Engineering Solutions has set itself as a prime manufacturer of vacuum pumps in India. Vacuum Pumps are ment to achieve vacuum upto 750 mm of HG. These Pumps offered by us are used for various industrial applications; Vacuum Pumps can withstand different pressures hence facilitating more workability.

  • Vacuum is one of the most versatile of power sources. It can lift, hold, compact, evacuate, move, dehydrate, agitate, actuate, form, rotate, filter, clean and simulate high altitude.
  • In printing, plastics, materials handling, food processing, packaging, health care and many other industries, vacuum is called upon to perform many essential functions.
  • Producing a vacuum for modern industrial applications requires a method of air removal that is simple, dependable and economical to operate and maintain.
  • All of these requirements are met by the Ingersoll-Rand T30 Air Cooled Reciprocating Single Stage and Two Stage Vacuum Pumps.
  • These pumps achieve vacuum upto 737 mm (29.0′ Hg) for single stage and upto 754.4 mm (29.7″ Hg) for two stage configuration, at sea level.
  • These dry type vacuum pumps are ideal for paper handling, food processing, vacuum forming, liquid transfer and many other applications.
Model Piston Displacement

CFM

Vacuum

(HG) INCH

Motor

HP

MAX-15 – V235 21.60 29.00 1.5
MAX-15 – V235T 10.80 29.60 1.5
MAX-15 – V244 34.60 29.00 2.0
MAX-15 – V244T 17.30 26.65 2.0
MAX-15 – V255 60.00 29.00 5.0
MAX-15 – V255T 30.00 29.70 5.0
MAX-15 – 7V 110.00 29.00 7.5
MAX-15 – 7VT 55.00 29.65 7.5
MAX-15 – 15V 149.60 29.20 10.0
MAX-15 – 15VT 99.00 29.65 10.0
